DETECTOR PIR / SLIM-PIR-PET SATEL

SLIM LINE
This is where highly efficient motion detection meets elegant design suitable for all interiors. Choose from a wide range of devices to perfectly match your needs. The SLIM LINE family consists of different PIR and dual-tech models with additional features: lighting, active IR anti-masking, and PET immunity.

ONE ENCLOSURE, MULTIPLE DEVICES
The elegant, slim enclosure is made of high quality plastic. The unified appearance of all the detectors makes it difficult for intruders to identify a specific model, and unifies the appearance of all motion detection devices.

Reliable motion detection
Unique lens
SLIM LINE detectors are equipped with dedicated lens, designed and manufactured in Japan for SATEL. Thanks to these lenses, the detection area can cover up to 20 m x 24 m, with a 90° viewing angle.

Reliable operation
The advanced next-generation motion detection algorithm guarantees reliable recognition of moving intruder throughout the whole surveillance area, without triggering unwanted alarms.

Dynamic adaptation of the algorithm to ambient temperature changes improves operational stability of the detectors.

Quick lens replacement
The lenses in all the models* can be quickly and easily replaced, allowing the SLIM LINE detectors to perfectly adapt to site features. Wide angle (WD) lenses are the standard fitting, but curtain (CT) and long range (LR) lenses are also available.

Resistance to animal movement
PET models are resistant to the movement of animals weighing up to 20 kg. Therefore, these models successfully monitor rooms with small pets present, without triggering unwanted alarms.

DUAL - two detection paths: PIR and MW
Dual technology detectors are equipped with a microwave sensor (MW), in addition to an infrared sensor (PIR). This significantly increases their resistance to unwanted alarms, caused by sudden temperature changes in protected areas, or air movement within their detection area.

Creep zone protection
The integrated swivel mirror in the LUNA* and PRO models enables effective observation of the area directly below the detectors – the so-called creep zone.

Cover attempt signalling
The PRO models feature an active anti-masking function using infrared radiation. Any attempts to disable the devices by covering the lenses (for example by tape, paint, or clear varnish) will be signalled.

Additional light source
The LUNA models feature specially built-in white LEDs. This allows the detectors to serve as motion responsive corridor lighting, especially during power outages. The lighting function can be controlled remotely or for a specified time when motion is detected.

Two sensitivity levels
Detection sensitivity of the LUNA models can be set remotely. This allows to change motion detection settings, and to adjust the detectors’ parameters depending on the partition they supervise. While the partition is not armed, the LUNA lighting can be switched on in response to the slightest movement. When the partition is armed, the detector can use settings appropriate to eliminate triggering of unwanted alarms.

Remote configuration
A very useful feature for installers, featured in the LUNA and PRO models, is the ability to remotely change the detectors operating parameters using the OPT-1 keyfob. This way the settings (including sensor sensitivity, operating mode, indicator light or LED lighting manner) can be changed easily, without actually opening the enclosure.

One indicator - many colours
SLIM LINE detectors offer a wide choice of LED indicator colours. Depending on the model, you can choose from four or seven colours.
If required, the indicator can be switched off.

• certificate of compliance with the EN 50131 requirements for Grade 2
• motion detection using passive infrared (PIR) sensor
• adjustable sensitivity of detection
• digital motion detection algorithm
• digital temperature compensation
• wide-angle lens, designed specifically for the SLIM LINE detectors
• pet immunity up to 20 kg
